Grey & Ductile (SG) Iron Casting Services
Engineered ferrous castings delivering high vibration dampening, compressive stability, and high-tensile structural integrity for heavy seating bases, industrial machinery, and automotive systems.
Ferrous Metallurgy & Molding Technologies
Specialized in high-density, defect-free iron pours with full microstructural nodularity checks and ultrasonic testing.
Grey Iron Casting (Flake Graphite)
Exceptional vibration damping capacity and excellent machinability, ideal for heavy seating pedestal footings, machine bases, and structural counterweights.
Ductile / S.G. Iron Casting (Spheroidal)
Offers steel-like tensile strength, high elongation, and superior impact resistance for high-stress pivots, brackets, and automotive safety components.
Weight Range & Foundry Envelopes
Single-piece heavy casting capability accommodated via automated green sand molding loops and resin-bonded no-bake mold lines.
Medium Frequency Induction Melting
Precise thermal management, metallurgical inoculation controls, and real-time optical emission spectrometry on every heat tap.
Core Making & Complex Cavities
High dimensional accuracy for complex internal water jackets, fluid passages, and lightweighted hollow structural ribs.
Heavy CNC Machining & Shot Blasting
Turnkey delivery of fully machined, cleaned, ultrasonic-tested, and primer-coated iron components ready for immediate line assembly.
Standard Cast Iron Grades & Properties
| Grade | Iron Type | Tensile Strength | Hardness / Ductility | Key Engineering Feature |
|---|---|---|---|---|
| FG 200 (Class 30) | Grey Iron | 200 MPa | 160-220 HB | Excellent thermal conductivity and superior acoustic/vibration dampening. |
| FG 260 (Class 40) | Grey Iron | 260 MPa | 180-240 HB | Higher mechanical stiffness for machine bedways and precision brackets. |
| GGG 40 (60-40-18) | Ductile Iron | 400 MPa | 15-18% | High fracture toughness and ductility for impact-loaded safety nodes. |
| GGG 50 (80-55-06) | Ductile Iron | 500 MPa | 7-10% | Optimum balance of tensile strength, fatigue endurance, and wear resistance. |
| GGG 70 (100-70-03) | Ductile Iron | 700 MPa | 3-5% | High hardness and yield strength replacing cast steel in heavy linkages. |
